6 Inch Submersible Pumps For Well

SUBMERSIBLE WELL PUMPS 5″ – 6″

Designed for maximum performance and efficiency for lower life cycle costs and reduced energy consumption. 6” submersible pump models carried by SLAPK feature stainless steel construction, impellers engineered to resist abrasion from sand, built-in thrust protection, and FDA compliant non-metallic parts.

Modular design features make field serviceability quick and easy when maintenance does become necessary.
Designed for 5” or larger water wells
Silent operation
Energy Efficient
VFD compatible

10HP TS6-200-03A 230V 3-Phase, Pump-end and Motor w/ Stainless Steel Impellers

Complete pump end and motor set. Control box (control panel) is not mandatory, but a three phase power switch with overload protection is required.

HP: 10HP
Voltage: 230V Three Phase
Cycle: 60 Hz
Operating Amperage: 26.4A
Motor RPM: 3450 RPM
Stages: 3
Maximum Head (cut off): 200 ft
Rated Flow: 200GPM
Maximum Flow( 0-100 ft.): 290 GPM
Free Flow Rate: 250GPM @ 130ft; 230GPM @ 140ft; 200GPM @ 158ft; 150GPM @ 178ft; 100GPM @ 190 ft.
Suction Port: Center Suction
Discharge Port: 4 inch NPT Female
Built-in Check-valve: Yes
Housing Material: Stainless Steel 304
Impeller Material: stainless steel 304
Motor Enclosure: Stainless steel 304
Discharge and Suction Port Material: Stainless Steel 304
Duty: Continuous or allow maximum 15 restarting cycles / hour
Motor Bearing / Lubrication: Ball bearing, oil filled lubrication
Control Box: Three phase power switch with overload protection is required(not included)
Net Weight: 120 lbs
Shipping weight: 129 Lbs

Single Phase 6″ Larger Deep Well Submersible Motors:

Single Phase, 6” motors available in 5 – 15 HP, 230 volt models.
Require CentriPro Control Boxes as shown on Order Number chart.

Three Phase 6″ Larger Deep Well Submersible Motors:

Three Phase, 6”, 5 – 30 HP, 230 and 460 volt models have an exclusive voltage change plug feature. Stock one model and a different voltage plug to reduce inventory cost.
Change Plug Order Numbers are: PLUG-230V and PLUG-460V
6 – 10” Three Phase available from 5 – 200 HP in 200, 230, 460 and 575 volt models.

The 6 inch canned design motor features a replaceable plug-in motor lead, moisture resistant insulation and a specially formulated patented resin that protects the motor against thermal fluctuation and internal stress.

The 8 to 10 inch rewindable water-tight motor has a coil conductor insulation material that is specially developed denatured polypropylene, which offers excellent leak-resistant characteristics. Three barriers are applied to the copper conductors to provide complete insulation against the motor’s cooling fluid.

This design is the result of extensive research and is of superior quality. It insures that CentriPro motors will have an extremely long service life.
