Water Pump Direct Sale
Professional Submersible Pump Manufacturer
Water Pump Direct Sale
Professional Submersible Pump Manufacturer
Three phase power: 7.5kW
Speed: 2850rpm
Voltage: 380V-415V ～/50Hz
Insulation class: B
Protection grade:IP 68
Highest temperature of liquid:35℃
Maximum content of solid substance: 40gr/m3
Flange and coupling according to NEMA standard
Motor casing： stainless steel
Maximum diameter: Φ95mm
With sand proof cover/ pressure balance membrane/
mechanical seal with high performance
E-mail: marketing@apkpump.com
WhatsApp: +86 175 3718 7726
SLAPK’ Encapsulated-resin filled motor is developed with market expectation to meet the robust construction and stringent requirement, which is for 6” or larger well. The motor is 100% tested before shipment.
| Brand | SLAPK |
| Manufacturer’s Warranty | 1 years Limited Warranty |
| Ship Weight | |
| Service Factor | 1.15 |
| Material | Stainless Steel 316 |
| Volts | 230 – Three Phase |
| In(A)
Imax Istart |
27.8
31.6 112.0 |
| HP | 10 |
| KW | 7.5 |
| R.P.M | 3450 |
| Power factor% (Allowable load)
Power factor% (Overload Factor) |
0.84
0.83 |
| Efficiency%(Allowable load)
Efficiency%(Overload Factor) |
79.1
77.7 |
| Need Capacitor
Need Starter |
No
Optional |
| Cable section (AWG) | 4 x 10 |
| Cable length (ft.) | 5.5 |
| Dimensions L x W x H (in.) | 5.5 x 5.5 x 26.1 |
| Product Weight (lbs.) | |
| Production Country | CHINA |
Grundfos SP range of 4″ – 10″ single or three phase submersible borehole pumps with hydraulic design, constructed entirely from corrosion resistant stainless steel AISI 304.
The Grundfos SP range can handle flows of up to 470 m3/h and heads up to 810m this guarantees a high-quality water supply which is reliable and efficient.
SP pumps provide low long-term costs and high operating reliability regardless of the application.
7.5kW 10HP 4″ Standard Submersible Motor can be installed on all wet ends with Spline Couplings.
Can be used on following pump ends: Franklin, Lowara, Davey, Southern Cross, Goulds, Onga, Sta-rite and Grundfos
Hermetically sealed stator, anti track self healing stator resin prevents motor burn out
Removable Water Bloc™ lead connector
Cable material according to drinking water regulations (VDE/ACS/KTW approved)
All motors are prefilled with water and 100% testedTechnical Specifications:
7.5 kW 4″ NEMA flange, Outside Diameter 95 mm
Starts per hour: max. 10 vertical or horizontal installation
Standard voltage: 415 V/50Hz FLC 17.4Amps
Voltage tolerance 50 Hz: 415 Volt AC -10% / +6%
Insulation: Class F Rated ambient temperature: 30°C
Single Motor lead in 2.5 meter length (VDE/ACS/KTW approved)
Types of starting DOL, Soft Starter, VSD or VFD
