8SP Deep Well Submersible Pump

─ 100%Copper Wire, Cold-Rolled Silicon Steel Sheet
─ Total Stainless Steel 304 or 316
─ Rewindable motor or Full obturated screen motor
─ Three-phase: 380V-415V/50Hz
─ Single-phase: 220V-240V/50Hz
─ Stall Protection, Phase Protection
─ Protection against reverse polarity
─ Equip with start control box or digital auto-control box
─ Pumps are designed by casing stressed
─ NEMA dimension standards
─ Curve tolerance according to ISO 9906

8SP Deep Well Submersible Pump Introduction

Pump body is well directly connecting with diving asynchronous motor, assembles into submersible pumps.

The diameter of the pump is 10 inch.

The power of this pump ranges from 11kw-100kw.Usually used for medium and large projects.We can recommend different

configurations according to customer needs, such as size, head, flow, etc., to meet different needs of customers.

The runners of our impellers are carefully designed and adjusted to adapt to motors of different powers.The number of impellers and the mismatch between the flow channel and the motor will cause many problemsIf the electronic power is too large, the cost performance of the water pump is too low.If the power of the water pump is too small, then the electronics will burn up after long-term high-load operation.

8SP submersible pump

8SP stainless steel multi-stage deep well submersible pump is a new type of machine for extracting groundwater.

It is widely used in industrial and mining enterprises for water supply, irrigation of farmland, and groundwater for self-use.

Since the pump main body is made of stainless steel, it is corrosion-resistant, wear-resistant, energy-saving and efficient.

Fully reliable, and because of its compact size, small size and light weight, it is very easy to maintain,

Transportation, installation and use, combined with automatic energy-saving and efficient control box, with over temperature, short circuit,

Overload and undervoltage overload protection, safe and reliable.

60Hz Mastra 8 inch stainless steel submersible pump – 8SP series 77 m³/h rated flow deep well jet pump double pipe

Metal parts for 8SP series of submersible pump such as impeller, diffuser, pump outlet and suction support etc. are made of wearable and anticorrosive stainless steel AISI304 through advanced moulding and punching craft procedures. Rubber bearing is made of wearable rubber with low friction. The connection method between coupler and motor is in compliance with standard of NEMA. Our impeller and diffuser are designed and manufactured according to the requirements of high efficiency, high reliabitity and long service life.

8 Inches 8sp Submersible Pump Deep Well Borehole Water Pump

Components Material
Pump external casing AISI 304 SS / 201 SS
Delivery casing ① Cast-Cu ASTM280 ② AISI 304 SS
Suction lantern ① Cast-Cu ASTM280 ② AISI 304 SS
Diffuser Plastic PC
Impeller Plastic POM
Shaft ① AISI 316 SS ② AISI 304 SS
Shaft coupling ① AISI 316 SS ② AISI 304 SS
Wear ring AISI 304 SS
Motor external casing AISI 304 SS
Top chock ① Cast- Cu ASTM280 ② Cast- iron G20UN|5007
Bottom support AISI 304 SS
Mechanical seal Special seal for deep well (Graphite-SiC/TC)
Shaft AISI 304 SS-C1045
Bearing NSK / C&U
Seal lubricant oil Oil for food machinery and pharmaceutic use
×
