Pump Outlet:80-800mm
Capacity:60-11,600m3/hr
Head:7-200m
Temperature:Max 105℃
Max Working Pressure：25 bar
Max solids content: 80mg/L
The majority of sewage pumps are installed at wastewater treatment plants and similar facilities, but they have many other uses. Large facilities like hotels, campgrounds, and amusement parks often rely on these pumps to move sewage to a distant holding tank or far-off sewer connection point. Any bathroom facility located below the sewage connection or septic tank will require some kind of pump to lift the slurry to its intended destination. Receiving stations that handle deliveries from septic tanks and portable toilet trucks also need these pumps to distribute the raw sewage to the various storage or processing areas.
These pumps are also required for other types of sewage that aren’t generated by human sources. The same slurry pumps used for bathroom facilities work well for moving valuable manure slurries around, which often feature solids even larger and more challenging to pump than those found in sewage. Manure processing can yield valuable fertilizer products while protecting local waterways from toxic runoff, but only if the treatment facility has the right slurry pumps for separating and moving the various raw materials.
SLAPK provides sewage pumps, non-clog Effluent pumps for Industrial / Commercial submersible heavy duty applications Non-clog sewage pumps also come in packaged pump systems with basin and rails.
Submersible Sewage and Effluent pumps come in single and three phase, all voltages, as well as a range of horsepower (from ½ HP to 300 HP), and various pressure and flow rates. These commercial sewage pumps include heavy duty long power cords but most often no plugs.
SLAPK can also provide a Rhombus pump control panel for these pumps.
Top selling Sewage & Effluent Pump Brands include Barnes, Barmesa, Ebara
Sewage pumps are designed to handle wastewater with suspended solids trash up to 2 inches. These pumps are designed to work with toilet waste discharge. Grinder Pumps are sewage pumps with grinder blades to reduce solids. Grinder sewage pumps start at 2HP.
EDDY Pump has a tested and multi-decade proven solution. The sewage systems of the US Navy have been using EDDY Pumps for many years. Read about the newest Ford Class using EDDY Pump HERE. Based on the EDDY Pump design which has a large and non-critical tolerance between the rotor and volute, it makes for the ideal sewage pump. The EDDY Pump can pass an object without any issue that is 1-inch smaller than the intake of the pump. For example, a 4-inch EDDY Sewage Pump can handle a 3-inch solid without clogging or having any negative effect on the pump. Another advantage of this extreme tolerance is reduced wear and tear because fewer solids come in contact with the rotor.
The EDDY Slurry Pump isn’t like other pump designs created for sewage handling. Only this pump harnesses the power of the eddy current to create a strong flow and plenty of suction with a small and open rotor. Since there’s no need for the rotor to pass close to the internal walls to generate pressure, very large solids can flow through without getting caught and causing a clog. The EDDY pump’s ability to handle a slurry with up to 70 percent solids and a high viscosity makes it ideal for handling sewage from bathrooms featuring ultra-low flow fixtures. Even with low levels of water, the pump manages to move the same amount of solids of distances up to one mile. With the right pump design, solids of up to 11 inches can pass without clogging the pump. There’s no need to deal with constant unclogging, fussy filters, or regular replacements due to abrasion or corrosion when you choose the EDDY pump.
are suited for liquid and chemical transfer, heating and cooling, recirculation, booster service, salt water pump tansfer and other industrial applications. Stainless Steel units are especially effective in applications where rust and/or corrosion can develop in systems. Semi-open impeller features self-cleaning ability that makes the unit useful in applications involving muddy or dirty liquids, as well as clean, clear fluids. Biodiesel production. Discharge position can be adjusted in 90° increments, with vent and 1/2″ drain plugs for all positions. Naval Bronze models feature a seal wash to rinse salt water from seal cavity. Pumps are close coupled to Totally Enclosed Fan Cooled motors (TEFC), Open Drip Proof (ODP) or Explosion Proof XP motors depending on the models. Pumps are not self-priming and require flooded suction.
Big flow rate self priming waste water pump, also named solid-liquid pump or trash pump, is featured by distinctive hydraulic design, with impeller restricted within a single impeller bowl connected by pumping chamber. When impeller rotates, the liquid inside pump produces violent axial vortex, thus making inlet vacuumized and outlet provided with head. In this way foreign substances can be discharged out of pumping chamber. That is to say ,its flow channel is fully cleared, making it’s discharging capability unparalleled compared with other self-priming pumps.
Big flow rate self priming waste water pump produced by our pump can be used like common clean water pump without bottom valve, also can suck and transfer big solid ,long fiber, sediment, waste ore impurities, faeces and all of engineer sewage.
| Type | Flow | Head | Power | NPSH | Efficiency | Speed |
| m3/h | m | kw | m | % | r/min | |
| ZW25-8-15 | 8 | 15 | 1.5 | 2.0 | 45 | 2900 |
| ZW32-10-20 | 10 | 20 | 2.2 | 2.5 | 45 | |
| ZW40-10-20 | 10 | 20 | 2.2 | 2.5 | 45 | |
| ZW40-15-30 | 15 | 30 | 3 | 3 | 48 | |
| ZW50-20-12 | 20 | 12 | 2.2 | 2.5 | 45 | |
| ZW50-20-35 | 20 | 35 | 5.5 | 2.5 | 48 | |
| ZW65-25-40 | 25 | 40 | 7.5 | 3.0 | 50 | |
| ZW65-65-25 | 65 | 25 | 7.5 | 3.0 | 52 | |
| ZW65-30-18 | 30 | 18 | 4 | 2.5 | 45 | 1450 |
| ZW80-40-16 | 40 | 16 | 4 | 3.0 | 50 | |
| ZW80-65-25 | 65 | 25 | 7.5 | 3.0 | 52 | 2900 |
| ZW80-80-35 | 80 | 35 | 15 | 3.0 | 50 | 1450 |
| ZW100-100-15 | 100 | 15 | 7.5 | 4.0 | 50 | |
| ZW125-120-20 | 120 | 20 | 15 | 4.5 | 55 | |
| ZW150-180-14 | 180 | 14 | 22 | 5.0 | 60 | |
| ZW200-280-28 | 280 | 18 | 55 | 4.8 | 55 | |
| ZW250-420-20 | 420 | 20 | 55 | 6.0 | 61 | |
| ZW300-800-14 | 800 | 14 | 55 | 6.0 | 65 |
