220V AC Three Phase Submersible Water Pump

Submersible Deep Well Pumps | 4 Inch 220V Three Phase 3 Ph

If you have access to three phase power supply, consider a 3Ph (Three Phase) SLAPK pump for maximum efficiency and reducing pump wire costs. 3 Phase power in general allows you to use smaller wire gauges to save money!

Listed here are SLAPK’s Three Phase deep well submersible pumps that run on Three Phase 220V You must have access to this kind of power source otherwise the pump won’t start!

HP: 5.5HP
Voltage: 220V Three Phase
Cycle: 60 Hz
Operating Amperage: 14.8 A
Motor RPM: 3450 RPM
Stages: 8
Maximum Head(cut off): 205 ft
Maximum Flow: 120 GPM @ 0-80 ft.
Free Flow Rates: 110GPM @ 105ft.; 90GPM @ 130ft; 75GPM @ 150ft.; 60GPM @ 165ft.; 50GPM @ 175ft.
Suction Port: Center Suction
Discharge Port: 2 in
Built-in Check-valve: Yes
Housing Material: Stainless Steel, Grade 304
Impeller Material: Thermal Plastic
Motor Enclosure: Stainless steel, Grade 304
Duty: Continuous or up to 30 restarting cycles / hour
Control Box: optional
Weight: 66 lbs

Deep Well Submersible Pump Motor: 5 HP, 3,450 Nameplate RPM, 220V AC, 3 Wires

Three-phase submersible deep-well pump AC motors don’t require starting capacitors, run capacitors, or centrifugal starting switches that can wear out and fail. They operate with a higher torque and greater efficiency than single-phase submersible deep-well pump motors of the same HP, rpm, and frame size.

2″ Thin Submersible Pump 5.2 GPM – 3 Wire – 170 Ft – 110/220V – 0.5HP

Rewindable motor
Single-phase:110V/60Hz or 220V/60Hz
Equip with start control box or digital auto-control box Pumps are designed by casing stressed Curve tolerance according to ISO 9906
Maximum fluid temperature up to +35
Maximum sand content : 0.25%
Minimum well diameter : 2.2″

Submersible Deep Well Pump: 20 gpm Nominal Flow Rate, 1 hp HP, 220V AC, 9.8 A Amps, 221 ft Max. Head

HP: 1 hp
Rated Voltage: 220V AC
Amps: 9.8 A
Phase – Pumps: 1
Number of Stages: 10
Number of Wires: 3
Discharge Head Material: Stainless Steel
Impeller Material: Celcon
Shaft Material: 303 Stainless Steel
